C Upper Palm (“FiveInch” Data)

C.1 Bootstrap Confidence for Segmentation Statistics

This section shows the same detailed results of segmentation of FiveInch data from Section 4.3, but with an added bootstrap confidence interval. For each observation, a bootstrap routine with 1 000 replicates was run, and a 95 % confidence interval extracted. The lower and upper confidence from that confidence interval are printed in each column within square brackets.

In Table C.1, results are shown of how successful Hisign+0008 segmented fingers for each subject in the test corpus. Table C.2 shows success for specific finger positions over the entire test corpus. Similarly, Table C.3 shows success for segmenting the same finger position from both hands.

The remainder of the tables show success per subject when considering combinations of subsets of the fingers in each slap image. Table C.4 shows success for combinations of all fingers, Table C.6 for the all except the little finger, and Table C.5 for just the index and middle fingers.

Table C.1: For each subject, the percentage that at least Number of Fingers fingers were correctly segmented, regardless of hand, for a maximum of eight correctly-segmented fingers. In Standard Scoring, scoring rules are followed exactly. In Ignoring Bottom Y, the bottom left and bottom right Y coordinates are ignored. Ignoring Bottom X and Y only checks the locations of the top left and top right coordinates. Values in square brackets represent a 95 % confidence interval after bootstrapping with 1 000 replicates.
Number of Fingers Standard Scoring Ignoring Bottom Y Ignoring Bottom X and Y
1 93.3 [91.4, 95.0] 93.3 [91.4, 95.0] 93.3 [91.4, 95.0]
2 90.0 [87.9, 92.0] 90.1 [88.0, 92.2] 90.1 [87.9, 92.1]
3 87.6 [85.1, 89.9] 87.7 [85.4, 90.1] 88.0 [85.5, 90.4]
4 84.6 [81.9, 87.2] 84.8 [82.2, 87.4] 84.8 [82.2, 87.3]
5 80.1 [77.5, 83.0] 80.2 [77.5, 83.0] 80.4 [77.5, 83.5]
6 73.8 [70.4, 76.7] 74.3 [71.4, 77.6] 74.4 [71.5, 77.7]
7 65.5 [61.9, 68.6] 66.1 [62.8, 69.4] 66.5 [63.0, 70.1]
8 51.6 [48.1, 55.2] 53.4 [49.8, 57.0] 54.7 [51.3, 58.1]
Table C.2: For all subjects, Percentage that a particular friction ridge generalized position was correctly segmented. In Ignoring Bottom Y, the bottom left and bottom right Y coordinates are ignored. Ignoring Bottom X and Y only checks the locations of the top left and top right coordinates. Values in square brackets represent a 95 % confidence interval after bootstrapping with 1 000 replicates.
Finger Standard Scoring Ignoring Bottom Y Ignoring Bottom X and Y
Right
Index 80.1 [77.1, 82.7] 80.2 [77.0, 83.0] 80.2 [77.3, 82.8]
Middle 75.8 [72.6, 78.9] 75.8 [72.7, 78.7] 76.3 [73.1, 79.3]
Ring 80.1 [76.9, 82.8] 80.5 [77.5, 83.0] 80.5 [77.7, 83.1]
Little 83.1 [80.5, 85.6] 84.3 [81.7, 87.0] 84.3 [81.6, 86.7]
Left
Index 79.8 [76.8, 82.8] 80.4 [77.6, 83.4] 80.6 [77.9, 83.4]
Middle 75.1 [71.6, 78.2] 75.1 [71.9, 78.2] 75.2 [72.0, 78.2]
Ring 79.2 [76.0, 82.0] 79.6 [76.4, 82.2] 79.8 [77.1, 82.9]
Little 78.4 [75.5, 81.2] 79.3 [76.4, 82.2] 80.4 [77.6, 83.2]
Table C.3: Percentage that a particular type of fingerprint was correctly segmented on Either or Both hands. In Ignoring Bottom Y, the bottom left and bottom right Y coordinates are ignored. Ignoring Bottom X and Y only checks the locations of the top left and top right coordinates. Values in square brackets represent a 95 % confidence interval after bootstrapping with 1 000 replicates.
Fingers Standard Scoring Ignoring Bottom Y Ignoring Bottom X and Y
Index
Either 87.4 [85.1, 89.6] 87.5 [85.1, 89.9] 87.5 [85.2, 89.7]
Both 71.3 [67.7, 74.8] 71.8 [68.6, 75.0] 72.1 [68.9, 75.2]
Middle
Either 82.7 [80.1, 85.4] 82.7 [80.0, 85.2] 83.0 [80.5, 85.5]
Both 66.9 [63.6, 70.2] 66.9 [63.6, 70.4] 67.3 [64.0, 70.6]
Ring
Either 86.0 [83.4, 88.4] 86.3 [83.7, 88.7] 86.4 [84.1, 88.8]
Both 71.9 [68.6, 75.1] 72.5 [69.4, 75.8] 72.6 [69.4, 75.5]
Little
Either 90.5 [88.4, 92.8] 91.4 [89.3, 93.3] 91.4 [89.5, 93.3]
Both 69.7 [66.4, 73.3] 70.9 [67.6, 74.0] 71.9 [68.8, 75.2]
Table C.4: Percentage of segmentation success by hand for combinations of all eight fingers of a FiveInch slap. In Ignoring Bottom Y, the bottom left and bottom right Y coordinates are ignored. Ignoring Bottom X and Y only checks the locations of the top left and top right coordinates. Values in square brackets represent a 95 % confidence interval after bootstrapping with 1 000 replicates.
Fingers Standard Scoring Ignoring Bottom Y Ignoring Bottom X and Y
Right
Any 89.5 [88.5, 91.5] 89.5 [88.6, 91.6] 89.5 [88.4, 91.6]
At Least Two 83.9 [81.6, 85.3] 84.0 [81.5, 85.4] 84.2 [81.7, 85.5]
At Least Three 78.3 [75.7, 79.7] 78.5 [75.7, 79.8] 78.6 [75.9, 80.1]
All Four 67.3 [62.2, 67.1] 68.8 [63.5, 68.1] 69.0 [64.5, 69.1]
Left
Any 90.6 [88.5, 91.5] 90.7 [88.6, 91.6] 90.7 [88.4, 91.6]
At Least Two 83.0 [81.6, 85.3] 83.0 [81.5, 85.4] 83.2 [81.7, 85.5]
At Least Three 77.1 [75.7, 79.7] 77.3 [75.7, 79.8] 77.5 [75.9, 80.1]
All Four 61.8 [62.2, 67.1] 63.3 [63.5, 68.1] 64.7 [64.5, 69.1]
Table C.5: Percentage of segmentation success by hand when only considering combinations of index and middle fingers. In Ignoring Bottom Y, the bottom left and bottom right Y coordinates are ignored. Ignoring Bottom X and Y only checks the locations of the top left and top right coordinates. Values in square brackets represent a 95 % confidence interval after bootstrapping with 1 000 replicates.
Fingers Standard Scoring Ignoring Bottom Y Ignoring Bottom X and Y
Right
Either Index or Middle 82.6 [80.9, 84.9] 82.6 [81.0, 84.7] 82.7 [81.1, 85.1]
Both Index and Middle 73.3 [70.1, 74.6] 73.4 [70.5, 75.2] 73.8 [70.8, 75.3]
Left
Either Index or Middle 83.4 [80.9, 84.9] 83.4 [81.0, 84.7] 83.4 [81.1, 85.1]
Both Index and Middle 71.5 [70.1, 74.6] 72.0 [70.5, 75.2] 72.4 [70.8, 75.3]
Table C.6: Percentage of segmentation success by hand when only considering combinations of index, middle, and ring fingers. In Ignoring Bottom Y, the bottom left and bottom right Y coordinates are ignored. Ignoring Bottom X and Y only checks the locations of the top left and top right coordinates. Values in square brackets represent a 95 % confidence interval after bootstrapping with 1 000 replicates.
Fingers Standard Scoring Ignoring Bottom Y Ignoring Bottom X and Y
Right
Any 84.6 [83.1, 86.7] 84.7 [83.1, 86.7] 84.7 [83.0, 86.9]
At Least Two 79.5 [77.3, 81.3] 79.5 [77.3, 81.4] 79.8 [77.6, 81.7]
All Three 71.8 [68.6, 73.1] 72.2 [69.1, 73.8] 72.5 [69.6, 74.1]
Left
Any 85.0 [83.1, 86.7] 85.1 [83.1, 86.7] 85.1 [83.0, 86.9]
At Least Two 79.2 [77.3, 81.3] 79.2 [77.3, 81.4] 79.4 [77.6, 81.7]
All Three 69.9 [68.6, 73.1] 70.7 [69.1, 73.8] 71.1 [69.6, 74.1]

C.2 Jaccard Index

Boxplot of Jaccard similarity indices as compared to the traditional success metrics. Outliers have been removed for clarity.

Figure C.1: Boxplot of Jaccard similarity indices as compared to the traditional success metrics. Outliers have been removed for clarity.

Boxplot of Jaccard similarity indices for each friction ridge generalized position. Outliers have been removed for clarity.

Figure C.2: Boxplot of Jaccard similarity indices for each friction ridge generalized position. Outliers have been removed for clarity.

Table C.7: For each subject, the percentage that at least Number of Fingers fingers were segmented with a Jaccard index in the indicated range.
Number of Fingers ≥0.5 ≥0.6 ≥0.7 ≥0.8 ≥0.9 ≥0.95 ≥0.98
1 100.0 100.0 99.9 99.9 93.1 39.0 27.8
2 100.0 100.0 99.9 99.5 78.1 22.5 21.6
3 99.6 99.5 99.3 99.2 60.7 18.6 18.1
4 98.9 98.9 98.9 98.4 39.4 14.6 14.4
5 97.5 97.5 97.2 95.3 24.1 10.8 10.4
6 94.1 93.9 93.5 89.1 12.9 8.3 8.3
7 88.1 87.9 87.5 78.0 7.6 6.9 6.9
8 76.2 75.4 72.3 55.2 5.5 5.3 5.3
Table C.8: For all subjects, percentage that a particular friction ridge generalized position was segmented with a Jaccard index in the indicated range.
Finger 0-0.5 0.5-0.6 0.6-0.7 0.7-0.8 0.8-0.9 0.9-1.0
Right
Index 6.4 0.1 0.4 1.6 39.6 51.9
Middle 3.7 0 0.1 5.2 54.0 37.0
Ring 3.2 0.3 0.1 2.5 47.5 46.4
Little 3.6 0.7 0.5 6.2 66.5 22.5
Left
Index 6.1 0 1.1 3.8 45.8 43.2
Middle 4.8 0.1 0.9 4.5 49.6 40.1
Ring 4.0 0 0.3 1.4 39.0 55.3
Little 7.8 0.1 1.1 9.0 54.1 27.9
Table C.9: Percentage of segmentation obtaining a Jaccard index in the indicated ranges, by hand, for combinations of all ten fingers of a FiveInch slap.
Fingers ≥0.5 ≥0.6 ≥0.7 ≥0.8 ≥0.9 ≥0.95 ≥0.98
Right
Any 100.0 100.0 99.9 99.7 78.3 26.7 21.8
At Least Two 98.8 98.8 98.7 98.3 46.8 16.9 16.4
At Least Three 96.0 95.6 95.5 93.1 22.9 12.0 11.7
All Four 88.3 87.6 86.8 74.2 9.7 8.2 8.2
Left
Any 99.7 99.7 99.6 99.5 82.2 29.6 21.9
At Least Two 98.3 98.3 98.3 96.8 51.1 15.6 15.6
At Least Three 95.2 95.2 94.7 89.7 24.0 11.1 11.1
All Four 84.1 83.8 81.2 69.0 9.2 6.8 6.8
Table C.10: Percentage of segmentation obtaining a Jaccard index in the indicated ranges, by hand, for combinations of index and middle fingers of a FiveInch slap.
Fingers ≥0.5 ≥0.6 ≥0.7 ≥0.8 ≥0.9 ≥0.95 ≥0.98
Right
Either Index or Middle 98.0 98.0 97.9 97.3 64.0 24.2 20.3
Both Index and Middle 91.9 91.8 91.4 85.1 24.9 12.5 12.1
Left
Either Index or Middle 98.3 98.3 98.3 96.9 61.9 22.9 20.2
Both Index and Middle 90.8 90.7 88.7 81.7 21.4 11.7 11.7
Table C.11: Percentage of segmentation obtaining a Jaccard index in the indicated ranges, by hand, for combinations of index, middle, and ring fingers of a FiveInch slap.
Fingers ≥0.5 ≥0.6 ≥0.7 ≥0.8 ≥0.9 ≥0.95 ≥0.98
Right
Any 99.3 99.3 99.2 99.1 75.5 26.2 21.1
At Least Two 97.5 97.2 97.2 96.0 41.1 16.5 16.1
All Three 89.9 89.8 89.2 81.2 18.6 11.2 11.2
Left
Any 99.6 99.6 99.5 99.3 78.8 27.9 21.5
At Least Two 97.1 97.1 97.1 94.8 43.1 15.3 15.3
All Three 88.5 88.3 86.2 78.8 16.7 11.0 11.0
