C Upper Palm (“FiveInch” Data)

C.1 Bootstrap Confidence for Segmentation Statistics

This section shows the same detailed results of segmentation of FiveInch data from Section 4.3, but with an added bootstrap confidence interval. For each observation, a bootstrap routine with 1 000 replicates was run, and a 95 % confidence interval extracted. The lower and upper confidence from that confidence interval are printed in each column within square brackets.

In Table C.1, results are shown of how successful Hisign+0007 segmented fingers for each subject in the test corpus. Table C.2 shows success for specific finger positions over the entire test corpus. Similarly, Table C.3 shows success for segmenting the same finger position from both hands.

The remainder of the tables show success per subject when considering combinations of subsets of the fingers in each slap image. Table C.4 shows success for combinations of all fingers, Table C.6 for the all except the little finger, and Table C.5 for just the index and middle fingers.

Table C.1: For each subject, the percentage that at least Number of Fingers fingers were correctly segmented, regardless of hand, for a maximum of eight correctly-segmented fingers. In Standard Scoring, scoring rules are followed exactly. In Ignoring Bottom Y, the bottom left and bottom right Y coordinates are ignored. Ignoring Bottom X and Y only checks the locations of the top left and top right coordinates. Values in square brackets represent a 95 % confidence interval after bootstrapping with 1 000 replicates.
Number of Fingers Standard Scoring Ignoring Bottom Y Ignoring Bottom X and Y
1 91.4 [89.3, 93.4] 91.4 [89.5, 93.4] 91.6 [89.6, 93.4]
2 85.8 [83.3, 88.1] 86.0 [83.5, 88.4] 86.0 [83.5, 88.5]
3 81.9 [79.1, 84.7] 82.5 [79.6, 85.1] 82.6 [79.8, 85.2]
4 78.5 [75.6, 81.4] 80.2 [77.6, 83.0] 80.2 [77.1, 83.1]
5 72.3 [69.2, 75.6] 73.0 [70.0, 76.1] 73.0 [69.7, 76.4]
6 66.9 [63.6, 69.8] 67.2 [63.8, 70.4] 67.3 [64.0, 70.8]
7 62.1 [58.8, 65.7] 64.2 [60.7, 67.3] 64.3 [60.7, 67.6]
8 48.9 [45.3, 52.4] 53.6 [50.1, 57.3] 54.8 [51.4, 58.4]
Table C.2: For all subjects, Percentage that a particular friction ridge generalized position was correctly segmented. In Ignoring Bottom Y, the bottom left and bottom right Y coordinates are ignored. Ignoring Bottom X and Y only checks the locations of the top left and top right coordinates. Values in square brackets represent a 95 % confidence interval after bootstrapping with 1 000 replicates.
Finger Standard Scoring Ignoring Bottom Y Ignoring Bottom X and Y
Right
Index 72.7 [69.5, 75.9] 72.9 [69.5, 76.1] 73.0 [69.8, 76.1]
Middle 72.5 [69.1, 75.7] 72.6 [69.7, 75.8] 72.9 [69.8, 76.1]
Ring 76.5 [73.5, 79.5] 77.5 [74.2, 80.6] 77.5 [74.7, 80.6]
Little 81.2 [78.5, 83.8] 83.6 [81.0, 86.4] 83.8 [81.2, 86.4]
Left
Index 79.0 [76.3, 82.1] 80.5 [77.7, 83.3] 80.5 [77.6, 83.6]
Middle 73.6 [70.2, 76.7] 73.9 [70.7, 76.9] 74.0 [70.8, 77.2]
Ring 73.1 [70.0, 76.0] 74.7 [71.5, 77.6] 74.7 [71.4, 77.9]
Little 63.9 [60.5, 67.1] 67.2 [63.8, 70.4] 68.3 [65.0, 71.5]
Table C.3: Percentage that a particular type of fingerprint was correctly segmented on Either or Both hands. In Ignoring Bottom Y, the bottom left and bottom right Y coordinates are ignored. Ignoring Bottom X and Y only checks the locations of the top left and top right coordinates. Values in square brackets represent a 95 % confidence interval after bootstrapping with 1 000 replicates.
Fingers Standard Scoring Ignoring Bottom Y Ignoring Bottom X and Y
Index
Either 84.3 [81.7, 86.8] 85.1 [82.5, 87.5] 85.2 [82.9, 87.9]
Both 66.3 [62.7, 69.7] 67.1 [63.6, 70.2] 67.1 [63.5, 70.5]
Middle
Either 80.9 [78.0, 83.8] 80.9 [78.1, 83.5] 81.0 [78.0, 83.8]
Both 64.0 [60.6, 67.5] 64.4 [61.1, 67.9] 64.7 [61.1, 68.0]
Ring
Either 83.1 [80.4, 85.9] 83.7 [80.9, 86.6] 83.7 [81.0, 86.3]
Both 65.2 [61.8, 68.6] 67.3 [64.0, 70.9] 67.3 [63.9, 70.5]
Little
Either 86.3 [83.8, 88.9] 89.2 [86.8, 91.4] 89.3 [87.1, 91.6]
Both 57.7 [54.2, 61.0] 60.5 [56.9, 64.0] 61.5 [58.0, 65.0]
Table C.4: Percentage of segmentation success by hand for combinations of all eight fingers of a FiveInch slap. In Ignoring Bottom Y, the bottom left and bottom right Y coordinates are ignored. Ignoring Bottom X and Y only checks the locations of the top left and top right coordinates. Values in square brackets represent a 95 % confidence interval after bootstrapping with 1 000 replicates.
Fingers Standard Scoring Ignoring Bottom Y Ignoring Bottom X and Y
Right
Any 86.7 [82.6, 86.4] 86.7 [82.7, 86.4] 86.8 [83.0, 86.6]
At Least Two 77.5 [74.2, 78.7] 77.9 [74.6, 79.0] 78.1 [74.6, 78.9]
At Least Three 73.4 [71.0, 75.4] 73.7 [71.5, 76.2] 73.8 [71.7, 76.0]
All Four 65.3 [59.6, 64.5] 68.4 [63.9, 68.7] 68.5 [64.6, 69.3]
Left
Any 82.2 [82.6, 86.4] 82.5 [82.7, 86.4] 82.5 [83.0, 86.6]
At Least Two 75.3 [74.2, 78.7] 75.5 [74.6, 79.0] 75.5 [74.6, 78.9]
At Least Three 73.2 [71.0, 75.4] 74.0 [71.5, 76.2] 74.0 [71.7, 76.0]
All Four 58.9 [59.6, 64.5] 64.3 [63.9, 68.7] 65.5 [64.6, 69.3]
Table C.5: Percentage of segmentation success by hand when only considering combinations of index and middle fingers. In Ignoring Bottom Y, the bottom left and bottom right Y coordinates are ignored. Ignoring Bottom X and Y only checks the locations of the top left and top right coordinates. Values in square brackets represent a 95 % confidence interval after bootstrapping with 1 000 replicates.
Fingers Standard Scoring Ignoring Bottom Y Ignoring Bottom X and Y
Right
Either Index or Middle 74.2 [75.9, 80.3] 74.3 [76.2, 80.3] 74.5 [76.4, 80.5]
Both Index and Middle 71.0 [68.5, 73.1] 71.1 [69.3, 74.0] 71.4 [69.6, 74.2]
Left
Either Index or Middle 82.0 [75.9, 80.3] 82.1 [76.2, 80.3] 82.1 [76.4, 80.5]
Both Index and Middle 70.7 [68.5, 73.1] 72.3 [69.3, 74.0] 72.4 [69.6, 74.2]
Table C.6: Percentage of segmentation success by hand when only considering combinations of index, middle, and ring fingers. In Ignoring Bottom Y, the bottom left and bottom right Y coordinates are ignored. Ignoring Bottom X and Y only checks the locations of the top left and top right coordinates. Values in square brackets represent a 95 % confidence interval after bootstrapping with 1 000 replicates.
Fingers Standard Scoring Ignoring Bottom Y Ignoring Bottom X and Y
Right
Any 77.9 [77.9, 82.0] 78.2 [78.2, 82.2] 78.2 [78.3, 82.3]
At Least Two 73.9 [72.4, 76.8] 74.1 [72.4, 76.8] 74.3 [72.6, 77.1]
All Three 69.8 [66.7, 71.2] 70.7 [68.7, 73.2] 70.9 [68.7, 73.4]
Left
Any 82.0 [77.9, 82.0] 82.4 [78.2, 82.2] 82.4 [78.3, 82.3]
At Least Two 75.2 [72.4, 76.8] 75.3 [72.4, 76.8] 75.3 [72.6, 77.1]
All Three 68.6 [66.7, 71.2] 71.4 [68.7, 73.2] 71.5 [68.7, 73.4]

C.2 Jaccard Index

Boxplot of Jaccard similarity indices as compared to the traditional success metrics. Outliers have been removed for clarity.

Figure C.1: Boxplot of Jaccard similarity indices as compared to the traditional success metrics. Outliers have been removed for clarity.

Boxplot of Jaccard similarity indices for each friction ridge generalized position. Outliers have been removed for clarity.

Figure C.2: Boxplot of Jaccard similarity indices for each friction ridge generalized position. Outliers have been removed for clarity.

Table C.7: For each subject, the percentage that at least Number of Fingers fingers were segmented with a Jaccard index in the indicated range.
Number of Fingers ≥0.5 ≥0.6 ≥0.7 ≥0.8 ≥0.9 ≥0.95 ≥0.98
1 99.2 99.2 98.9 98.9 83.5 27.9 22.0
2 98.9 98.9 98.7 97.9 62.7 18.6 18.1
3 97.9 97.8 97.4 95.9 41.8 15.2 15.0
4 94.7 94.5 93.5 91.0 26.1 12.8 12.6
5 88.1 88.0 87.5 83.9 15.9 9.6 9.6
6 82.5 82.3 81.6 75.1 9.9 7.8 7.8
7 74.3 73.8 72.7 60.1 5.9 5.8 5.8
8 69.2 67.6 63.0 42.0 5.0 4.9 4.9
Table C.8: For all subjects, percentage that a particular friction ridge generalized position was segmented with a Jaccard index in the indicated range.
Finger 0-0.5 0.5-0.6 0.6-0.7 0.7-0.8 0.8-0.9 0.9-1.0
Right
Index 13.0 0.1 0.5 3.2 45.0 38.2
Middle 10.0 0 0.6 6.8 53.2 29.4
Ring 9.0 0.3 0.4 3.4 51.1 35.8
Little 5.8 0.5 1.5 7.6 61.7 22.9
Left
Index 10.6 0.3 1.7 7.0 52.8 27.6
Middle 11.7 0.3 1.0 7.4 47.9 31.7
Ring 9.0 0 0.9 3.4 40.9 45.8
Little 20.3 1.3 2.1 9.8 44.9 21.6
Table C.9: Percentage of segmentation obtaining a Jaccard index in the indicated ranges, by hand, for combinations of all ten fingers of a FiveInch slap.
Fingers ≥0.5 ≥0.6 ≥0.7 ≥0.8 ≥0.9 ≥0.95 ≥0.98
Right
Any 96.8 96.8 96.5 96.4 66.2 20.6 17.7
At Least Two 94.7 94.7 94.5 92.4 34.4 14.0 13.8
At Least Three 87.9 87.8 87.4 83.2 17.0 12.1 12.1
All Four 82.7 81.9 79.7 65.0 8.5 7.8 7.8
Left
Any 96.6 96.6 96.2 95.2 67.9 21.0 17.2
At Least Two 91.2 91.2 90.8 89.4 37.0 13.4 13.4
At Least Three 82.8 82.5 82.0 75.6 14.5 7.8 7.8
All Four 77.9 76.3 71.8 52.8 7.3 6.6 6.6
Table C.10: Percentage of segmentation obtaining a Jaccard index in the indicated ranges, by hand, for combinations of index and middle fingers of a FiveInch slap.
Fingers ≥0.5 ≥0.6 ≥0.7 ≥0.8 ≥0.9 ≥0.95 ≥0.98
Right
Either Index or Middle 91.4 91.4 91.2 89.9 49.3 18.4 17.3
Both Index and Middle 85.6 85.5 84.4 75.8 18.2 12.8 12.8
Left
Either Index or Middle 95.6 95.6 95.4 92.4 45.9 14.9 13.9
Both Index and Middle 82.1 81.6 79.0 67.5 13.4 7.4 7.4
Table C.11: Percentage of segmentation obtaining a Jaccard index in the indicated ranges, by hand, for combinations of index, middle, and ring fingers of a FiveInch slap.
Fingers ≥0.5 ≥0.6 ≥0.7 ≥0.8 ≥0.9 ≥0.95 ≥0.98
Right
Any 94.9 94.9 94.8 94.1 60.6 20.1 17.7
At Least Two 88.4 88.4 88.2 85.4 28.3 14.0 13.8
All Three 84.6 84.2 83.0 73.0 14.4 11.7 11.7
Left
Any 96.4 96.4 96.0 94.8 63.7 19.4 16.6
At Least Two 91.0 91.0 90.6 86.9 31.3 13.3 13.3
All Three 81.3 80.8 77.9 64.9 10.1 7.4 7.4
