8 IARPA N2N (Sequestered)

The results in Section 8 are based on searches of the dataset IARPA N2N (Sequestered). Images in this dataset were collected during the IARPA Nail to Nail (N2N) Fingerprint Capture Challenge. The subjects whose fingerprints are the source of this data are not present in NIST Special Database 302.2

All probes searched were a single sample primarily depicting a single region from a distal phalanx. As is common, some probes may contain overlapping impressions or multiple touches. Only subject-level ground truth information is provided. All images in this dataset were analyzed by International Association for Identification (IAI) Certified Latent Print Examiners (CLPE) under guidance from NIST.

8.1 Suitable for Automated Searching

This section includes results from searches of fingermark images whose content was determined to be suitable for Automated Biometric Identification System (ABIS) searches by a CLPE3. For each image, three CLPE followed guidance from ANSI/ASB BPR 165 [1] to determine this level of utility. Images were downsampled to 1000 pixels per inch and quantized to a single grayscale color channel of 8 bits.

CLPE annotated all EFS data manually. CLPE were not provided with a mated exemplar source during probe annotation. When EFS data was provided to algorithms under test for this dataset, it could contain:

  • Always:
    • Region of interest
    • Ridge quality map
  • When ascertainable:
    • Complexity
    • Core locations
    • Delta locations
    • Examiner analysis assessment
    • Minutiae locations
    • Orientation
    • Pattern classification

8.1.1 Failures

Table 8.1 shows the number of failures to create templates. Table 8.2 shows the number of failures to produce a candidate list.

Table 8.1: Number of failures to create templates.
Image Type Content Failures Attempts
Exemplar Image 0 346
Probe Image 1 2 272
Table 8.2: Number of failures to produce a candidate list. This number includes any failures to create a probe template from Table 8.1.
Probe Content Failures Attempts
Image 1 2 272

8.1.2 CMC

8.1.2.1 Plots

The CMC plots in Figure 8.1 show the FNIR of Neurotechnology+0125 when searching IARPA N2N (Sequestered) against enrollment database where a single mated identity for each search probe was present. Tabular versions of FNIR at select ranks can be viewed in Table 8.3.

CMC when searching IARPA N2N (Sequestered) probes.

Figure 8.1: CMC when searching IARPA N2N (Sequestered) probes.

8.1.2.2 FNIR at Select Rank

The values in Table 8.3 correspond to Figure 8.1.

Table 8.3: Region FNIR values from CMC plotted in Figure 8.1.
Probe Content Rank 1 Rank  ≤ 2 Rank  ≤ 5 Rank  ≤ 10 Rank  ≤ 50 Rank  ≤ 100
Image 0.2042 0.195 0.1844 0.1791 0.1712 0.1668

8.1.3 DET

8.1.3.1 Plots

The DET plots in Figure 8.2 show the false positive and false negative identification rate tradeoffs of Neurotechnology+0125 when searching IARPA N2N (Sequestered) against enrollment database where a single mated identity for each search probe was present. Tabular versions of FNIR at select FPIR can be viewed in Table 8.4. Annotated values indicate similarity scores from the Subject line, which are tabulated in Table 8.5.

DET when searching IARPA N2N (Sequestered) probes. Annotated values indicate similarity scores from the Subject line.

Figure 8.2: DET when searching IARPA N2N (Sequestered) probes. Annotated values indicate similarity scores from the Subject line.

8.1.3.2 FNIR at Select FPIR

The values in Table 8.4 correspond to Figure 8.2.

Table 8.4: Subject FNIR values corresponding to FPIR plotted in Figure 8.2.
Probe Content FPIR = 0.01 FPIR = 0.02 FPIR = 0.1
Image 0.2799 0.2588 0.2227

8.1.3.3 Similarity Score Thresholds at Select FPIR

The values in Table 8.5 correspond to similarity score thresholds observed at the select FPIR values from Table 8.4.

Table 8.5: Similarity score thresholds corresponding to select FPIR values from Table 8.4.
Probe Content FPIR = 0.01 FPIR = 0.02 FPIR = 0.1
Image 69 67 63

References

[1]
“ANSI/ASB best practice recommendation 165: Best practice recommendation for analysis of friction ridge impressions,” Academy Standards Board, 2024. Available: https://www.aafs.org/asb-standard/best-practice-recommendation-analysis-friction-ridge-impressions

  1. Organizations who participated in the IARPA N2N Fingerprint Capture Challenge may have collected and retained exemplar fingerprints from these subjects with their own capture devices, but they have not received the images used in this test.↩︎

  2. This designation is often referred to as “of value for ABIS” [1].↩︎
